Large Image :  Electric Steel Poles, Electric Steel Monopoles, Electric Transmission Poles, Electric Lighting Poles

Product Details:
Place of Origin: CHINA
Brand Name: TB or OEM
Certification: CE
Model Number: Electric Poles Series
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Packaging Details: Standard Package
Delivery Time: 20-40 work days
Payment Terms: T/T
Supply Ability: 10000 PCS Per Month
Contact Now

Electric Steel Poles, Electric Steel Monopoles, Electric Transmission Poles, Electric Lighting Poles

Description
Material:: Carbon Steel Q235 Height:: 3m-11.8m
Color:: HDG, Black, Etc. Wall Thickness:: 3mm-6mm
Galvanization Thickness:: 60um-100um Warranty:: Galvanized: 5 Years

Features of Straight Round Poles:



•Height=2m~11.7m;



•Steel Materials: Q235,Q345,SS400 or any equivalent;



•Welding: Welding complies with CSA, AWS, Australian/New Zealand standard, or BS EN 40-5; All sharp edges and burrs are removed;



•Finish: Hot-dip galvanization to ASTM A123-01/ISO1461 or be color powder coating after galvanization or powder coating only;



•Customized lighting poles available.





Poles Specifications:





Straight Round Poles
Items

Pole Top Size

(mm)

Pole Bottom Size

(mm)

Wall Thickness

(mm)

Base Plate Size

(mm)

 PCD(mm)

Anchor Bolts Size

(mm)
4m straight round poles 89 89 3 233x233x16 233 M20X700
5m straight round poles 89 89 3 233x233x16 233 M20X700
5.5m straight round poles 102 102 3 233x233x16 233 M20X700
6m straight round poles 114 114 3 233x233x16 233 M20X1200
8m straight round poles 165 165 3 330x330x20 350 M20X1500
9m straight round poles 165 165 3 330x330x20 350 M24X1400
