Product Details:

Place of Origin:	CHINA
Brand Name:	TB or OEM
Certification:	CE
Model Number:	Stepped Lighting Poles Series

Payment & Shipping Terms:

Contact Now

Description

Material::	Carbon Steel Q235	Color::	HDG, Black, Etc.
Height::	3m-11.8m	Wall Thickess::	3mm-6mm
Base Plate Thickness::	16mm-30mm	Galvanization Thickness::	60um-100um
Powder Coating Thickness::	80um-180um	Designed Gust Wind::	26m/s-50m/s
Life Span::	Based On The Application Condition	Warranty::	Galvanized: 5 Years; Galvanzied And Powder Coated: 5 Years

Features of Straight Stepped Round Lighting Poles:

•Height=2m~11.7m;

•Steel Materials: Q235,Q345,SS400 or any equivalent;

•Welding: Welding complies with CSA, AWS, Australian/New Zealand standard, or BS EN 40-5; All sharp edges and burrs are removed;

•Finish: Hot-dip galvanization to ASTM A123-01/ISO1461 or be color powder coating after galvanization or powder coating only;

•Customized lighting poles available.

Lighting Poles Specifications:

Straight Stepped Round Lighting Poles
Items	Pole Top Size (mm)	Pole Bottom Size (mm)	Wall Thickness (mm)	Base Plate Size (mm)	PCD(mm)	Anchor Bolts Size (mm)
4m straight round poles	89	89	3	233x233x16	233	M20X700
5m straight round poles	89	89	3	233x233x16	233	M20X700
5.5m straight round poles	102	102	3	233x233x16	233	M20X700
6m straight round poles	114	114	3	233x233x16	233	M20X1200
8m straight round poles	165	165	3	330x330x20	350	M20X1500
9m straight round poles	165	165	3	330x330x20	350	M24X1400
