Product Details:

Place of Origin:	CHINA
Brand Name:	TB or OEM
Certification:	CE
Model Number:	Straight Round Lighting Poles Series

Payment & Shipping Terms:

Contact Now

Description

Material::	Carbon Steel Q235	Color::	HDG, Black, Etc.
Wall Thickness::	3mm-5mm	Base Plate Thickness::	16mm-30mm
Pole Height::	3-11.8m	Anchor Bolts::	M20-M30
Galvanization Thickness::	60um-100um	Powder Coating Thickness::	60um-180um
Designed Gust Wind::	26m/s-50m/s	Life Span::	Based On The Application Condition
Warranty;:	5 Years

Features of Straight Round Lighting Poles:

•Height=2m~11.7m;

•Steel Materials: Q235,Q345,SS400 or any equivalent;

•Welding: Welding complies with CSA, AWS, Australian/New Zealand standard, or BS EN 40-5; All sharp edges and burrs are removed;

•Finish: Hot-dip galvanization to ASTM A123-01/ISO1461 or be color powder coating after galvanization or powder coating only;

•Customized lighting poles available.

Lighting Poles Specifications:

Straight Round Lighting Poles
Items	Pole Top Size (mm)	Pole Bottom Size (mm)	Wall Thickness (mm)	Base Plate Size (mm)	PCD(mm)	Anchor Bolts Size (mm)
4m straight round poles	89	89	3	233x233x16	233	M20X700
5m straight round poles	89	89	3	233x233x16	233	M20X700
5.5m straight round poles	102	102	3	233x233x16	233	M20X700
6m straight round poles	114	114	3	233x233x16	233	M20X1200
8m straight round poles	165	165	3	330x330x20	350	M20X1500
9m straight round poles	165	165	3	330x330x20	350	M24X1400
