Tapered Octagoanl Lighting Poles, Octagonal Solar Lighting Poles, Octagonal Flood Lighting Poles, LED Flood Light Poles

Tapered Octagoanl Lighting Poles, Octagonal Solar Lighting Poles, Octagonal Flood Lighting Poles, LED Flood Light Poles
Tapered Octagoanl Lighting Poles, Octagonal Solar Lighting Poles, Octagonal Flood Lighting Poles, LED Flood Light Poles Tapered Octagoanl Lighting Poles, Octagonal Solar Lighting Poles, Octagonal Flood Lighting Poles, LED Flood Light Poles Tapered Octagoanl Lighting Poles, Octagonal Solar Lighting Poles, Octagonal Flood Lighting Poles, LED Flood Light Poles Tapered Octagoanl Lighting Poles, Octagonal Solar Lighting Poles, Octagonal Flood Lighting Poles, LED Flood Light Poles

Large Image :  Tapered Octagoanl Lighting Poles, Octagonal Solar Lighting Poles, Octagonal Flood Lighting Poles, LED Flood Light Poles

Product Details:
Place of Origin: CHINA
Brand Name: TB or OEM
Certification: CE
Model Number: Octagonal Lighting Poles Series
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Packaging Details: Standard Package
Delivery Time: 20-40 work days
Payment Terms: T/T
Supply Ability: 10000 PCS Per Month
Contact Now

Tapered Octagoanl Lighting Poles, Octagonal Solar Lighting Poles, Octagonal Flood Lighting Poles, LED Flood Light Poles

Description
Material:: Carbon Steel Q235 Color:: HDG, Black, Etc.
Height:: 3m-30m Wall Thickness:: 3mm-6mm
Base Plate Thickness:: 16mm-40mm Anchor Bolts:: M20-M42
Designed Gust Wind:: 26m/s-50m/s Life Span:: Based On The Application Condition
Warranty;: 5 Years

Features of Tapered Octagonal Lighting Poles:



•Height=2m~30m;



•Steel Materials: Q235,Q345,SS400 or any equivalent;



•Welding: Welding complies with CSA, AWS, Australian/New Zealand standard, or BS EN 40-5; All sharp edges and burrs are removed;



•Finish: Hot-dip galvanization to ASTM A123-01/ISO1461 or be color powder coating after galvanization or powder coating only;



•Customized lighting poles available.







Lighting Poles Specifications:





Tapered Octagonal Lighting Poles
Items

Pole Top Size

(mm)

Pole Bottom Size

(mm)

Wall Thickness

(mm)

Base Plate Size

(mm)

 PCD(mm)

Anchor Bolts Size

(mm)
4.5m tapered octagonal poles 85 135 3 233x233x16 233 M20X700
5m tapered octagonal poles 85 142 3 233x233x16 233 M20X700
5.5m tapered octagonal poles 85 152 3 233x233x16 233 M20X700
6m tapered octagonal poles 85 157 3 233x233x16 233 M20X1200
8m tapered octagonal poles 85 172 3 330x330x20 350 M20X1500
9m tapered octagonal poles 85 185 3 330x330x20 350 M24X1400



Tapered Octagoanl Lighting Poles, Octagonal Solar Lighting Poles, Octagonal Flood Lighting Poles, LED Flood Light Poles 0
