Hot Dip Galvanized Lighting Poles, Tapered Octagonal Lighting Poles, Powder Coated Lighting Poles, Lighting Columns

Large Image : Hot Dip Galvanized Lighting Poles, Tapered Octagonal Lighting Poles, Powder Coated Lighting Poles, Lighting Columns

Product Details:

Place of Origin:	CHINA
Brand Name:	TB/OEM
Certification:	CE
Model Number:	Tapered Octagonal Lighting Poles

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Packaging Details:	Standard Package
Delivery Time:	15-35 Work Days
Payment Terms:	T/T
Supply Ability:	10000 PCS Per Month

Contact Now

Hot Dip Galvanized Lighting Poles, Tapered Octagonal Lighting Poles, Powder Coated Lighting Poles, Lighting Columns

Description

Material::	Carbon Steel Q235 Or Low Alloy Steel Q345	Color::	HDG, Powder Coated Black, Bronze, Etc.
Height::	2m-30m	Wall Thickness::	3mm-6mm
Base Plate Thickness::	12mm-40mm	Anchor Bolts::	M20-M42
Galvanization Thickness::	60um-100um	Powder Coating Thickness::	More Than 180um
Designed Wind Speed::	26m/s-56m/s	Pole Lifespan::	More Than 30 Years
Warranty::	Powder Coated Only: 1 Year; Galvanized Only: 5 Years; Galvanized And Powder Coated Finish: 5 Years

Features of Tapered Octagonal Lighting Poles:

•Height=2m~30m;

•Steel Materials: Q235,Q345,SS400 or any equivalent;

•Welding: Welding complies with CSA, AWS, Australian/New Zealand standard, or BS EN 40-5; All sharp edges and burrs are removed;

•Finish: Hot-dip galvanization to ASTM A123-01/ISO1461 or be color powder coating after galvanization or powder coating only;

•Customized lighting poles available.

Lighting Poles Specifications:

Tapered Octagonal Lighting Poles
Items	Pole Top Size (mm)	Pole Bottom Size (mm)	Wall Thickness (mm)	Base Plate Size (mm)	PCD(mm)	Anchor Bolts Size (mm)
4.5m tapered octagonal poles	85	135	3	233x233x16	233	M20X700
5m tapered octagonal poles	85	142	3	233x233x16	233	M20X700
5.5m tapered octagonal poles	85	152	3	233x233x16	233	M20X700
6m tapered octagonal poles	85	157	3	233x233x16	233	M20X1200
8m tapered octagonal poles	85	172	3	330x330x20	350	M20X1500
9m tapered octagonal poles	85	185	3	330x330x20	350	M24X1400
