Product Details:
Place of Origin: CHINA
Brand Name: TB or OEM
Certification: CE
Model Number: LED Lighting Poles Series
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Packaging Details: Standard Package
Delivery Time: 20-40 work days
Payment Terms: T/T
Supply Ability: 10000 PCS Per Month
Contact Now

LED Lighting Columns, LED Lighting Metal Poles, LED Lighting Shafts, Conical LED Lighting Poles, Round LED Lighting Pole

Description
Material:: Carbon Steel Q235 Color:: HDG, Black, White, Silver, Bronze, Green, Etc.
Height:: 3m-20m Wall Thickness:: 3mm-5mm
Base Plate Thickness:: 16mm-30mm Galvanization Thickness:: 60um-100um
Powder Coating Thickness:: More Than 180um Designed Gust Wind:: 26m/s-50m/s
Life Span:: Based On Application Area Condition Warranty:: Powder Coated Only: 1 Year; Galvanized: 5 Years; Galvanzied And Powder Coated: 5 Years

Features of Tapered Round Lighting Poles:



•Height=2m~20m;



•Steel Materials: Q235,Q345,SS400 or any equivalent;



•Welding: Welding complies with CSA, AWS, Australian/New Zealand standard, or BS EN 40-5; All sharp edges and burrs are removed;



•Finish: Hot-dip galvanization to ASTM A123-01/ISO1461 or be color powder coating after galvanization or powder coating only;



•Customized lighting poles available.





Lighting Poles Specifications:





Tapered Round Lighting Poles
Items

Pole Top Size

(mm)

Pole Bottom Size

(mm)

Wall Thickness

(mm)

Base Plate Size

(mm)

 PCD(mm)

Anchor Bolts Size

(mm)
4.5m tapered round poles 85 135 3 233x233x16 233 M20X700
5m tapered round poles 85 142 3 233x233x16 233 M20X700
5.5m tapered round poles 85 152 3 233x233x16 233 M20X700
6m tapered round poles 85 157 3 233x233x16 233 M20X1200
8m tapered round poles 85 172 3 330x330x20 350 M20X1500
9m tapered round poles 85 185 3 330x330x20 350 M24X1400



LED Lighting Columns, LED Lighting Metal Poles, LED Lighting Shafts, Conical LED Lighting Poles, Round LED Lighting Pole 0
