Product Details:

Place of Origin:	CHINA
Brand Name:	TB or OEM
Certification:	CE
Model Number:	Intelligent Lighting Poles Series

Payment & Shipping Terms:

Contact Now

Description

Material::	Carbon Steel Q235; Low Alloy Steel Q345	Height::	5m-10m
Wall Thickness::	4mm-6mm	Base Plate Thickness::	20mm-30mm
Galvanization::	Hot Dip Galvanized	Powder Coating::	Polyster Powder Coated
Designed Gust Wind::	30m/s-45m/s	Life Span:	More Than 30 Years
Warranty::	Galvanized: 5 Years; Galvanzied And Powder Coated: 5 Years

Features of Intelligent Lighting Poles:

•Height=2m~20m;

•Steel Materials: Q235,Q345,SS400 or any equivalent;

•Welding: Welding complies with CSA, AWS, Australian/New Zealand standard, or BS EN 40-5; All sharp edges and burrs are removed;

•Finish: Hot-dip galvanization to ASTM A123-01/ISO1461 or be color powder coating after galvanization or powder coating only;

•Customized lighting poles available.

Intelligent Lighting Poles Specifications:

Intelligent Lighting Poles
Items	Pole Top Size (mm)	Pole Bottom Size (mm)	Wall Thickness (mm)	Base Plate Size (mm)	PCD(mm)	Anchor Bolts Size (mm)
4.5m tapered round poles	85	135	3	233x233x16	233	M20X700
5m tapered round poles	85	142	3	233x233x16	233	M20X700
5.5m tapered round poles	85	152	3	233x233x16	233	M20X700
6m tapered round poles	85	157	3	233x233x16	233	M20X1200
8m tapered round poles	85	172	3	330x330x20	350	M20X1500
9m tapered round poles	85	185	3	330x330x20	350	M24X1400
