Square Metal Poles, Square Steel Poles, Square Lighting Poles, Square Poles, Square Columns

Name: Square Metal Poles, Square Steel Poles, Square Lighting Poles, Square Poles, Square Columns
Brand: NINGBO TBL CO., LTD
SKU: Square Lighting Poles Series
Availability: InStock

All Products

SQUARE LIGHTING POLES
(7)

TAPERED ROUND LIGHTING POLES
(10)

STRAIGHT ROUND LIGHTING POLES
(7)

TAPERED OCTAGONAL LIGHTING POLES
(6)

HINGED LIGHTING POLES
(6)

LIGHTING POLE ACCESSORIES
(9)

Best Products

Square Metal Poles, Square Steel Poles, Square Lighting Poles, Square Poles, Square Columns

I'm Online Chat Now

Square Metal Poles, Square Steel Poles, Square Lighting Poles, Square Poles, Square Columns

Large Image : Square Metal Poles, Square Steel Poles, Square Lighting Poles, Square Poles, Square Columns

Product Details:

Place of Origin:	CHINA
Brand Name:	TB or OEM
Certification:	CE
Model Number:	Square Lighting Poles Series

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Packaging Details:	Standard Package
Delivery Time:	20-40 work days
Payment Terms:	T/T
Supply Ability:	10000 PCS Per Month

Contact Now

Square Metal Poles, Square Steel Poles, Square Lighting Poles, Square Poles, Square Columns

Description

Material::	Carbon Steel Q235	Color::	HDG, Bronze, Black, Etc.
Height::	2m-11.7m	Wall Thickness::	3mm-5mm
Base Plate Thickness::	16mm-25mm	Anchor Bolts::	M20 Or M24
Galvanization Thickness::	60um-100um	Powder Coating Thickness::	More Than 180um
Designed Gust Wind::	26m/s-50m/s	Pole Life Span::	Normally HDG And Powder Coated Finish More Than 30 Years
Warranty::	Powder Coated Only: 1 Year; Galvanized Only: 5 Years; Galvanized And Powder Coated: 5 Years

Features of Square Lighting Poles:

•Height=2m~11.7m;

•Steel Materials: Q235,Q345,SS400 or any equivalent;

•Welding: Welding complies with CSA, AWS, Australian/New Zealand standard, or BS EN 40-5; All sharp edges and burrs are removed;

•Finish: Hot-dip galvanization to ASTM A123-01/ISO1461 or be color powder coating after galvanization or powder coating only;

•Customized lighting poles available.

Lighting Poles Specifications:

Square Lighting Poles
Items	Pole Top Size (mm)	Pole Bottom Size (mm)	Wall Thickness (mm)	Base Plate Size (mm)	PCD(mm)	Anchor Bolts Size (mm)
10ft square poles	100/102	100/102	3	customized	customized	M20X700
15ft square poles	100/102	100/102	3	customized	customized	M20X700
20ft square poles	100/102	100/102	3	customized	customized	M20X700
25ft square poles	100/102	100/102	3/4/5	customized	customized	M20X700
30ft square poles	12-	12-	3/4/5	customized	customized	M24X900
35ft square poles	12-	12-	4/5	customized	customized	M24X900
